Configuration
| Feeding System | Side Lay Regulator | Electromagnetic Heating Technology |
| Anti-Curling Device | High Speed Collection | Film Laminating Machine |
| Man-Machine Interface System | Powder Removing Device | Rotary-Knife Cutting System |
Technical Parameters
| Model | YX-800SC | YX-1100MC | YX-1100LC | YX-1300LC |
| Max. Laminating Length | 780mm | 1080mm | 1080mm | 1280mm |
| Machine Sheed | 10-100m/min | 10-120m/min | 10-120m/min | l0-120m/min |
| Applicable Sheet Size | 780*900-350*350mm | 1080*1200-350*350mm | 1080*1450-350*350mm | 1300* 1650-350*350mm |
| Applicable Sheet Weight | 100-500g/㎡ | 100-500g/㎡ | 100-500g/㎡ | 100-500g/㎡ |
| Total Power | 28KW | 32KW | 32KW | 34KW |
| Overall Weight | 7500kg | 8000kg | 8500kg | 9000kg |
| Dimension | 9500*2050*2100mm | 10975*2300*2150mm | 11805*2300*2150mm | 12085*2550*2150mm |
