Configuration
| Feeding System | Side Lay Regulator | Electromagnetic Heating |
| Anti-Curling Device | High Speed Collection | Film Laminating Machine |
| Man-Machine Interface System | Powder Removing Device | Chain-Knife Cutting System |
Technical Parameters
| Model | YL-1100MC | YL-1100LC | YL-1300LC |
| Max. Laminating Length | 1080mm | 1080mm | 1280mm |
| Laminating Sheed (Chain Cutting) | 10-85m/min | 10-85 m/min | l0-85m/min |
| Laminating Sheed (Rotary Cutting) | 10-120m/min | 10-120 m/min | l0-120m/min |
| Applicable Sheet Size | 1080*1200-350*350mm | 1080*1450-350*350mm | 1300* 1650-350*350mm |
| Applicable Sheet Weight | 100-500g/㎡ | 100-500g/㎡ | 100-500g/㎡ |
| Total Power | 35KW | 35KW | 37KW |
| Overall Weight | 8300kg | 8800kg | 9300kg |
| Dimension | 11710*2300*2150mm | 12520*2300*2150mm | 12825*2550*2150mm |
